The Patented Hyperscale

SWK™ CONNECTOR

Available Now: The Next-Generation Connector For Your Connected Network Infrastructure

The revolutionary SWK™ Connector by Swick™ Designs is a game changer. This groundbreaking fiber optics connector delivers the highest strand capacity in the smallest form factor at the lowest loss attenuation. Some call it the perfect solution: the SWK™ Connector is self-cleaning and self-protecting, with features that bring levels of efficiency and flexibility never before seen in the industry.

Key Features

Highest capacity fiber optics connector available
Lowest loss attenuation
Self-cleaning, self-protecting Shield Shroud
Rapid Flip quick polarity change technology
Extending Reach-and-Release handle
Multimedia capabilities

Two flexible sizes:

SWK™ L Connector supports 32f – 192f strands
SWK™ S Connector supports duplex (2f) or QFSP (8f – 12f) configurations

Core Benefits

Maximize your fiber strand capacity with minimal loss and signal degradation
Cut costs with the lowest cost-per-connection solution in the industry
Eliminate connectivity problems: the self-cleaning Shield Shroud reduces debris and contaminants up to 98.99%
Choose the connector that adapts to your specific connectivity requirements, today and tomorrow – no need to change infrastructure

Product Construction

Number of Optical Fibers

96f strands. 32f, 48f, 64f, 144f and 192f strand configurations also available

Types of Optical Fibers

Single mode (OS2, ITU-T G654.D, G.657. A1 compliant) or multimode*

Cable Sheath

OFNP rated, OD: 9.0 mm (±10%), and LSZH (available upon request)

Cord Sheath

OFNP rated, OD: 3.0 mm, and LSZH (available upon request)

Cable Blend Radius

Installation: 180 mm. Operation: 90mm

Cord Band Radius

Bend radius of 24c fiber round cord: 25 mm

Cable Weight

60 kg/km

Performance Characteristics

Connector Type

SWK™ 96f Strand

Optical Fiber Type

Single mode

Insertion Loss @ 1310nm

< 0.35dB

Return Loss @ 1310nm

> 55dB

Temperature Range

Connector: -40 to 70°C
Connector: -20 to 70°C

The Revolutionary SWK™ Product Line

Today’s connected network infrastructure faces unprecedented demands from cloud and hyperscale growth and their extraordinary connectivity requirements. Our revolutionary SWK™ cabling infrastructure products are designed specifically to provide high density and low loss connectivity, ease of installation and manageability, low-cost deployment and operations, and flexibility for growth and scale.

SWK™ CONNECTOR

This patented breakthrough in connectivity technology was created to make the user capable again.

Features the highest fiber strand capacity in a single connector interface.
Outperforms with the lowest loss attenuation in a multi-strand platform.
Boasts a remarkable rotating, covering Shield Shroud that cleans the ferrule faces and protects them from contaminants, making cleaning kits and dust caps a thing of the past.

Uses our innovative Rapid Flip technology so that polarity adjustments can be done on the fly.
Provides optimal control and the most efficient use of space with our patented Reach-and-Release handle.
Multimedia capable: Hosts fiber, copper, and more within a single connection.
